Monday, March 14, 2016

The PCI-E x4 Ribbon flexible Cable more perfect than M.2+U.2 solution


United States Patean:
Patean No: US9,215,834 B2
Date of Patean: Dec. 15, 2015
Applicant: Chen Liang Ho or Liang Ho Chen


PCIE Gen 3.0 Ribbon flexible Cable x4 to x16 3D MARK11 benchmark






PCI-E Gen 3.0 Ribbon flexible Cable x4 to x16

Blue PCIE slot
Length:330mm Width:32.5mm Thickness:2.2mm

Black PCIE slot
Length:400mm Width:23mm Thickness:1.7mm


Black PCIE slot Thickness:1.7mm


Blue PCIE slot Thickness:2.4mm

Black PCIE slot Width:23mm

Blue PCIE slot Width:32.5mm



We will launch a PCI-E Gen 3.0 Ribbon flexible
Width 82mm cut to width ≒ 50
